The PCS410 is a 2-in-1 device, designed specifically for our RJLink range of equipment. It allows our RJLink interconnect system to interface with a DANTE or AES67 IP audio network. It incorporates both an 8-in/8-out DANTE/AES67 audio converter and a 24V/1.5A power supply with overload protection.

The PCS410 can power up to 18 PCS304, PMI103 or PRF75A units.

It includes in a slimrack:

•     8 analog audio inputs to 4 RJLink inputs
•     8 analog audio outputs to 4 RJLink outputs

An LED indicator shows the presence of audio modulation on each RJLink input/output.

Each 24V power output is protected against short circuits by an automatically resettable protection circuit. LED indicator for overload on each output.

Compatible with XRJ102 M or XRJ102 F adapters. This equipment allows easy interfacing of a stereo audio connection on XLR.

ACCESSORIES:

• FRT100: Front panel adapter for fitting one “SLIMRACK”.
• FRT200: Rack 19" 1U front panel adapter for 2 “SLIMRACK” units.
• FRT300: Cover plate for FRT200.
